HPE ProLiant DL180 Generation9 (Gen9)

Delivering an optimised 2U server, designed with the right balance of expandability, performance, reliability, and manageability all in a new compact chassis.

The ideal platform for SMBs and enterprises running applications, which need the right mix of compute and storage.




HPE ProLiant DL180 Gen9 E5 v4 - 4 Bay LFF 4x3.5 - Non Hot-Plug
Configure
From: £1,601.13

LFF Large Form Factor Drives

Fixed Drives

4 Drives

Xeon E5 2600 v4

HPE ProLiant DL180 Gen9 E5 v4 - 8 Bay LFF 8x 3.5
Configure
From: £1,614.82

LFF Large Form Factor Drives

Hot-Swap Drives

8 Drives

Xeon E5 2600 v4

HPE ProLiant DL180 Gen9 E5 v4 - 8 Bay SFF 8x 2.5
Configure
From: £1,650.32

SFF Small Form Factor Drives

Hot-Swap Drives

1TB 16x 64GB RDIMM @2400MHz

8 Drives

Xeon E5 2600 v4

HPE ProLiant DL180 Gen9 E5 v4 - 12 Bay LFF 12x 3.5
Configure
From: £1,727.60

LFF Large Form Factor Drives

Hot-Swap Drives

12 Drives

Xeon E5 2600 v4


Do you need a cost-effective server that can keep pace with your data growth while providing options to manage and deliver performance?

The HPE ProLiant DL180 Gen9 Server delivers an optimized 2U server, designed with the right balance of expandability, performance, reliability and manageability all in a new compact chassis, making it the ideal platform for SMBs and Enterprises running the "New Style of IT", applications such as Hadoop, Cloud and mobility applications which need right mix of compute and storage.

  • New SAS LFF hard disk drives with up to 10 TB capacity now bring maximum storage capacity to 120 TB SAS.
  • Docker ready support.
  • Microsoft® Windows® 2016 support.

Affordable Storage and IO Expandability for Service Providers and SMBs

The HPE ProLiant DL80 Gen9 Server provides ample storage capacity with up to (12) Large Form Factor (LFF) HPE SmartDrives, delivering optimal performance, capacity, and reliability to meet various customer segments and workload requirements at the right economics.

Up to (6) PCIe 3.0 riser slots to support one single-wide GPU or networking cards offering increased IO bandwidth and seamless expandability.

Comes standard with 2x1GbE and choice of HPE FlexibleLOM to provide you flexibility of networking bandwidth and fabric so you can adapt to changing business needs.

With support for Large Form Factor (LFF) hard disk drives (HDDs) with up to 10 TB capacity DL80 Gen9 offers maximum storage of up to 120 TB SAS/SATA.

Scalability and Performance to Meet the New Standard of Growing Data Center Needs

The HPE ProLiant DL180 Gen9 Server provides ample storage capacity on demand with drive configurations ranging from (4) to (12) Large Form Factor (LFF) or (8) to (16) Small Form Factor (SFF) HPE SmartDrives, with flexibility of LFF non-hot plug (NHP) options at the right economics.

It supports up to two Intel® Xeon® processor E5-2600 v3/v4 processors with up to (12) cores and (16) DIMM slots of HPE DDR4 SmartMemory offering improved performance and efficiency.

Comes standard with 2x1GbE and choice of HPE FlexibleLOM or PCIe standup 1GbE or 10GbE adapters provide you flexibility of networking bandwidth and fabric so you can adapt and grow to changing business needs.

Up to six PCIe 3.0 riser slots to support a wide range of GPUs and networking cards offering increased I/O bandwidth and seamless expandability.

Embedded SATA HPE Dynamic Smart Array B140i Controller for boot and data. Choice of HPE Smart Array Controllers with increased performance, data availability with 12 Gb/s SAS technology or HPE Smart HBAs with reliable high performance SAS connectivity capable of running HBA mode or simple RAID mode.

High Availability and Efficiency for Dense Storage Applications

The HPE ProLiant DL180 Gen9 Server supports HPE SmartDrive technology which improves serviceability and prevents data loss with features, such as, self-describing LEDs and a Do Not Remove icon.

HPE SmartMemory prevents data loss and downtime with enhanced error handling. Support of up to 512 GB maximum capacity with speeds up to 2133 MHz with up to 14%1 performance gain.

80 PLUS certified, entry-level, redundant HPE Power Supplies provide up to 92% efficiency which combined with Hewlett Packard Enterprise power management features lead to reduction of power consumption.

Improved ambient temperature standard with ASHRAE A3 and A42 helps customers reduce cooling expense.

ENERGY STAR® qualified server configurations illustrate a continued commitment to helping customers conserve energy and save money.



Agile Infrastructure Management for Accelerating IT Service Delivery

With HPE ProLiant DL180 Gen9 Server, HPE OneView provides infrastructure management for automation simplicity across servers, storage and networking.

Online personalized dashboard for converged infrastructure health monitoring and support management with HPE Insight Online.

Configure in UEFI boot mode, provision local and remote with HPE Intelligent Provisioning and Scripting Toolkits.

Embedded management to deploy, monitor and support your server remotely, out of band with HPE iLO.

Optimize firmware and driver updates and reduce downtime with HPE Smart Update, consisting of HPE SUM (Smart Update Manager) and HPE SPP (Service Pack for ProLiant).

Technical Specifications:

Processor family

  • Intel® Xeon® E5-2600 v3 product family
  • Intel® Xeon® E5-2600 v4 product family

Number of processors

  • 1 or 2

Processor core available

  • 18 or 16 or 14 or 12 or 10 or 8 or 6 or 4

Processor cache

  • 10MB L3
  • 15MB L3
  • 20MB L3
  • 25MB L3
  • 30MB L3
  • 35MB L3
  • 40MB L3
  • 45MB L3

Processor speed

  • 3GHz

Form factor (fully configured)

  • 2U

Form factor chassis

  • Rack

Power supply type

  • (2) Entry-Level

Expansion slots

  • (6) Maximum - For detail descriptions reference the QuickSpec

Memory, maximum

  • 1TB

Memory slots

  • 16 DIMM slots

Memory type

  • DDR4 SmartMemory

Drive description

  • (4) LFF SAS/SATA/SSD or
  • (12) LFF SAS/SATA/SSD
  • (8) SFF SAS/SATA/SSD or
  • (16) SFF SAS/SATA/SSD
  • Hot plug and/or Non-hot plug, depending on model

System fan features

  • Non-hot plug redundant optional

Network controller

  • 1Gb 361i Ethernet Adapter 2 Ports per controller and/or
  • Optional FlexibleLOM on riser
  • Depending on model

Storage controller

  • (1) Dynamic Smart Array B140i and/or
  • (1) H240 Host Bus Adapter and/or
  • (1) Smart Array P840
  • Depending on model

Infrastructure management

  • iLO Management (standard), Intelligent Provisioning (standard), iLO Essentials(optional), iLO Scale-Out(optional) iLO Advanced (optional)

Warranty

  • 3/1/1 Server Warranty includes three years of parts, one year of labor, one year of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: www.hpe.com/services/support. Additional Hewlett Packard Enterprise support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to www.hpe.com/services/support
